DLP-550: Detailed Level Procedure 365-575-102
Page 14 of 16 Issue 8.0, July 2002
!
CAUTION:
To remove a lead, grip it by the neck of the lead’s short plastic sleeve and not by
the lead itself.
Remove the power leads from the defective module.
11. Loosen the large set screw that is to the right of the modular unit while holding
the filter in place. The screw is captive, so it will not fall off.
12. Gently pull on the defective power line filter module or power-filter assembly,
andslideitout.
13. Orient and plug in the new power line filter module.
14. Tighten the large set screw that is to the right of the modular unit while holding
the filter in place.
15. Plug each lead back into the appropriate connector.
Reference: Figure 6 on page 15.
16.
!
CAUTION:
DO NOT ALLOW the screws to fall into the bay.
Put the User Panel back on and screw in the User Panel screws.
17. Reinstall the fuse.
Reference: DLP-515, Replace Fuse in Power Distribution and Fuse
Panel or User Panel Steps 6 and 7.
18. Did the alarm clear in approximately five minutes?
If NO, call your next level of support.
If YES,
STOP! YOU HAVE COMPLETED THIS PROCEDURE.
