About This Document
Issue 8.0 July 2002
xlvii
Lucent Technologies Drawings
The following Lucent Technologies drawings provide information about the FT-
2000 OC-48 Lightwave System:
J68974AK-1
FT-2000 OC-48 Lightwave Terminating Bay (Circuit
Packs, Miscellaneous Hardware, and Spare Parts Shipped
Separately from Equipment)
J68974D-1
FT-2000 OC-48 Dual Lightwave Terminating
Bay(Equipment and Circuit Packs Ordered with
Equipment)
J68974E-1
FT-2000 OC-48 Enhanced Lightwave Terminating
Bay(Equipment and Circuit Packs Ordered with
Equipment)
J68974EK-1
FT-2000 OC-48 Enhanced Lightwave Terminating Bay
(Circuit Packs, Miscellaneous Hardware, and Spare Parts
Shipped Separately from Equipment)
J68974ES-1
FT-2000 OC-48 Enhanced Lightwave Terminating Bay
(Software and Documentation)
J68974R-1
FT-2000 OC-48 Lightwave Repeater Bay (Equipment and
Circuit Packs Ordered with Equipment)
J68974RK-1
FT-2000 OC-48 Lightwave Repeater Bay (Circuit Packs,
Miscellaneous Hardware, and Spare Parts Shipped
Separately from Equipment)
J68974RS-1
FT-2000 OC-48 Lightwave Repeater Bay (Software and
Documentation)
SD-5G250-01
FT-2000 OC-48 Lightwave Terminating Bay Application
Schematic
SD-5G250-02
FT-2000 OC-48 Enhanced Lightwave Terminating Bay
Application Schematic
SD-5G250-03
FT-2000 OC-48 Dual Lightwave Terminating Bay
Application Schematic
SD-5G252-01
FT-2000 OC-48 Lightwave Repeater Bay Application
Schematic
T-5G250-31
FT-2000 Lightwave Transmission System OC-48
Lightwave Terminating Bay Interconnect Circuit
T-5G250-33
FT-2000 Lightwave Transmission System OC-48
Enhanced Lightwave Terminating Bay Interconnect Circuit
