Administration and Provisioning
Issue 8.0 July 2002
8-87
■ At CO 1, an OC-3 DCC assignment is entered by specifying:
— Low-speed interface slot (slot 5B)
— DCC (channel 3
*
)
— Orientation (network
†
).
■ At CO 2, an OC-3 DCC assignment is entered by specifying:
— Low-speed interface slot (slot 2A)
— DCC (channel 6*)
— Orientation (network
†
).
For more information about entering OC-3 DCC assignments in an FT-2000
OC-48 Add/Drop-Rings Terminal, refer to the CIT Tutorial in Volume I, Section 11,
"Craft Interface Terminal Usage," and the Operation Task Index in the "Operation
and Maintenance (TOP)" section (Volume II).
* The DCC assignment may be specified as channel 1-8 at each FT-2000 OC-48
Add/Drop-Rings Terminal.
† If the orientation is specified “network” at the FT-2000 OC-48 Add/Drop-Rings Terminal, the
DDM-2000 OC-12 Multiplexer must be specified “user.”
