Craft Interface Terminal Usage
11-58 Issue 8.0 July 2002
Releases 3 and 4.0
The above report shows an STS-3 cross-connection map that exists in the
FT-2000 OC-48 Add/Drop-Rings Terminal. Tributaries 1, 3, 5, 6, and 8 through 16
are 2-way pass-through cross-connections. Slots 1a, 1b, and 4b are 2-way
added/dropped cross-connections. Examples of cross-connections and additional
information are provided in Volume I, Section 8.
The fields of the report are described below:
Source/
Destination
Node ID
- Shows the node identifier and may be either the source node
or the destination node.
1W Trib - Shows the tributary (1 through 16) originating or terminating
on line 1W.
Slot - Shows the slot number where the STS3 signal is
added/dropped in this network element.
1E Trib - Shows the tributary (1 through 16) terminating or originating
on line 1E.
Source/
Destination
Node ID
- Shows the node identifier of either the destination node or
the source node.
Lucent Technologies-FT-2000 96-07-19 23:15:15 EST
M Retrieve-Crossconnection-STS3: COMPLD
/* STS-3 Cross-Connection Map Report
============================================================================
Source/ Source/
Destination 1W 1E Destination
Node ID Trib Slot Slot Trib Node ID
============================================================================
4 1 <------------------------> 1 2
?2 2 ?
1 3 <------------------------> 3 2
3 4 <-----> 1a 4 ?
4 5 <------------------------> 5 2
2 6 <------------------------> 6 4
3 7 <-----> 1b 4b <-----> 7 3
1 8 <------------------------> 8 1
2 9 <------------------------> 9 4
4 10 <------------------------> 10 2
:: : : :
2 16 <------------------------> 16 4
*/
;
