365-575-102 Acceptance: NTP-007
Issue 8.0, July 2002 Page 1 of 4
Accept FT-2000 2-Fiber Ring Network
DO ITEMS BELOW IN ORDER LISTED . . . . . . . FOR DETAILS, GO TO
1. Overview: This acceptance procedure for the FT-2000 2-fiber ring network can be
performed from any FT-2000 add/drop-rings terminal in the network. This
acceptance procedure is performed after all of the FT-2000 add/drop-rings
terminals and FT-2000 repeater bay/shelves or FT-Lightwave Booster Amplifiers
(FT-LBA) in the network have been individually acceptance tested.
Required Test Equipment:
Craft Interface Terminal (CIT)
Wrist Strap
!
WARNING:
Unterminated optical connectors may emit invisible laser radiation. Eye
damage may occur if beam is viewed directly or with improper optical
instruments. Avoid direct exposure to beam.
!
CAUTION:
Use a static ground wrist strap whenever handling circuit packs or working on
an FT-2000 terminal to prevent electrostatic discharge damage to sensitive
components. See "Electrostatic Discharge (ESD) Considerations" in Trouble
Clearing: TAD-100.
NOTE:
This procedure is only used if the FT-2000 2-fiber ring network was installed
by someone else. If the installation has not been completed, notify the
installation personnel or refer to 365-575-115 to complete the installation. If
you completed the installation following the procedures in 365-575-115,
do not perform this procedure.
NOTE:
Each FT-2000 network element should have been individually acceptance
tested. If this has not been done, refer to Acceptance: NTP-006 for the
FT-2000 add/drop-rings terminal, or Acceptance: NTP-011 for the FT-2000
add/drop-rings terminal for operation with an FT-LBA, and/or to Acceptance:
NTP-005 for the FT-2000 repeater bay/shelf.
If at any point in this
procedure any FT-2000 network element fails to respond in the indicated
way, refer the trouble to installation personnel.
