NTP-009: Acceptance 365-575-102
Page 2 of 12 Issue 8.0, July 2002
NOTE:
These tests pertain to a single path through a local FT-2000 ring that can
have up to 16 nodes. The path being tested can encounter either one or
two DRI cross-connections as it enters and/or leaves a ring per the
examples in Figures 1 through 5.
NOTE:
Assistance is required at the remote source/destination access points in
the external network or at the test sets when connected directly to the
local FT-2000 ring.
NOTE:
Path testing should be accomplished by using an end-to-end arrangement
as shown in Figure 6. However, due to equipment availability, another
possibility includes a loopback arrangement (Figure 7).
NOTE:
It is assumed that acceptance testing of the local FT-2000 ring has
passed.
If at any point in this procedure the local FT-2000 ring fails to
respond in the indicated way, refer the trouble to installation
personnel.
Referring to Figures 1 through 5, which figure
most closely represents your configuration?
If Figure 1, then continue with Step 2.
If Figure 2, then continue with Step 11.
If Figure 3, then continue with Step 20.
If Figure 4, then continue with Step 33.
If Figure 5, then continue with Step 47.
—
2. The local FT-2000 ring has one DRI cross-connection to the outside. Both DRI
cross-connections and local source/destination cross-connections terminate
directly to test sets.
Verify that there are no alarm or status conditions in
thering(Figure1).
—
DO ITEMS BELOW IN ORDER LISTED . . . . . . . FOR DETAILS, GO TO
