90-824052R3 JUNE 2002 FUEL SYSTEMS - 3A-3

Fuel Pump

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 1 FUEL PUMP ASSEMBLY

2 1 DIAPHRAGM KIT

3 2 CHECK VALVE– plastic

4 2 RETAINER

5 1 GASKET–boost

6 1 CAP

7 1 SPRING

8 2 DIAPHRAGM

9 1 GASKET–pulse

10 1 SPRING

11 1 CAP

12 1 GASKET–base

13 1 BASE–fuel pump

14 1 PLATE–fuel pump

15 1 ELBOW

16 1 FUEL LINE (6 IN.)

17 1 ELBOW

18 2 STA STRAP

19 2 SCREW–fuel pump to crankcase 55 6.0

20 2 SCREW–fuel pump 55 6.0
