• Perform low pressure checks (page 3D-23) be-
fore performing checks on high pressure route.
• Install fuel pressure gauge (P/N 91-16850A2)
on to manifold pressure port.
• Place ignition switch in “OFF” position 30 sec-
onds before testing.
• Place ignition switch in “ON” position and note
pressure within 30 seconds (34 to 36 psi; 234 to
248 kPa).
No or low fuel pressure Pump does not runFuel pressure above 36 psi (248 kPa)
Perform Final Filter Check
(page 3D-29).
Clogged or faulty fuel pressure
regulator remove and replace.
Perform Electric Fuel Pump Volt-
age Test (page 3D-31).
Final filter OK. Final filter clogged.
Perform Fuel Pressure Regula-
tor Test (page 3D-31).
Clean or replace final filter.
Steady stream of fuel (pressure
still below 34 psi).
Low or no fuel flow.
Replace fuel regulator.
Perform Electric Fuel Pump Vol-
tageTest (page 3D-31).
Voltage from ECM driver circuit
OK.
Low or inconsistent voltage from
ECM driver circuit.
Replace fuel pump. Replace ECM.
Results Results
Results
Results
Results
Results
3D-24 - FUEL SYSTEMS 90-824052R3 JUNE 2002
EFI Fuel Management (High Pressure Fuel Route)
