90-824052R3 JUNE 2002 FUEL SYSTEMS - 3D-55

6. Disconnect bleed line hoses from manifold

fittings.

7. Remove manifold assembly and place on clean

work surface.

51795

a - Bleed Hoses

EFI Induction Manifold

Disassembly

1. Remove manifold cover seal from manifold.

51785

a - Manifold Cover Seal

b - Manifold

Air Temperature Sensor Removal

1. Remove screws and sensor.

51790

a - Screws

b - Sensor

2. Remove O-ring from sensor.

51791

a - O-Ring

b - Sensor
