90-824052R3 JUNE 2002 LOWER UNIT - 6A-1

Gear Housing Specifications

(Standard Rotation)

PINION DEPTH

Gear Case Pinion Depth

1.87:1 (15/28 teeth)

and 2.00:1

(14/28 teeth)

Ratios

0.025 in. (0.635mm)

With Tool 91-12349A2

using Disc #2 and

Flat #7

2.3:1 (13/30 teeth)

Ratio

0.050 in. (1.27mm)

With Tool 91-12349A2

using Disc #2 and

Flat #7

REVERSE GEAR BACKLASH

Gear Case

Reverse Gear

Backlash

All Ratios 0.030 in. to 0.050 in.

(0.762mm to 1.27mm)

FORWARD GEAR BACKLASH

Gear Case &

Ratio

Backlash

Inches (mm)

Dial Indicator

Pointer on

Line Mark

Production

1.87:1

.018-.027

(.46-.69)

91-78473

CLE/Torque

Master/Sport

Master 1.87:1

.021-.026

(.53-.66)

91-78473

All 2.00:1 .015-.022

(.38-.56)

91-78473

All High Alti-

tude 2.3:1

.018-.023

(.46-.58)

91-19660

LUBRICANT CAPACITY

Gearcase Lubricant Capacity

All Ratios 22.5 fl. oz. (665.4ml)

Special Tools
