3C-62 - FUEL SYSTEMS 90-824052R3 JUNE 2002

Oil Reservoir Installation

1. Install oil reservoir to engine. Connect hose to

fitting and secure with hose clamp.

2. Install studs, nuts, and mounting bracket. Secure

reservoir using screws.

51791

a - Studs

b - Nuts

c - Bracket

d - Screws

Throttle Position Sensor and

Temperature Sensor Fuel Injector

Harness Connections

1. Connect fuel injector harness at 4 pin connector.

51787

a - Injector Harness

b - 4 Pin Connector

2. Connect air temperature sensor at connectors.

51788

a - Air Temperature Sensor

b - Connectors
