6C-6 - LOWER UNIT 90-824052R3 JUNE 2002

Gear Housing (Prop Shaft) - XR6/Magnum III - 1.78:1 Ratio

Super Duty Gear Lubricant (92-13783A24)

Anti-Corrosion Grease (92-78376A6)

2-4-C With Teflon (92-825407A12)

RTV Silicone Sealer (92-91601-1)

Loctite 271 (92-809820)
