4A-46 - POWERHEAD 90-824052R3 JUNE 2002
PORT SIDE VIEW
50934
a
b
a - To Vapor Separator Thru Bleed Shut-Off Valve (0G303045
and Below) – Direct to Vapor Separator (0G303046 and
Above)
b - To Bottom of EFI Manifold if Equipped
STARBOARD SIDE VIEW
50935
a
b
a - To Vapor Separator Thru Bleed Shut-Off Valve (0G303045
and Below) – Direct to Vapor Separator (0G303046 and
Above)
b - To Bottom of EFI Manifold if Equipped
Reinstalling Engine
Components
Reinstall the following engine components:
Section 2
Starter Motor
Ignition Switch Boxes
Ignition Coil
Starter Solenoid
Voltage regulator/rectifier
Flywheel
Stator Assembly
Trigger Assembly
Low speed/high speed spark advance module
Idle Stabilizer
Section 3
Air Silencer
Carburetors and Linkage
Fuel Pump
Fuel Enrichment Valve
Warning Module
On-Board Oil Tank
Oil Pump
Fuel Injection Assembly
Section 7
Shift Cable Latch Assembly
Control Cable Anchor Bracket
To Next Page
