90-824052R3 JUNE 2002 LOWER UNIT - 6D-1
Gear Housing Specifications
(Standard Rotation)
Ratio Pinion
Depth
Forward
Gear
Backlash
Reverse
Gear
Backlash
1.87:1
(15/28
teeth)
0.025 in.
(0.635mm)
With Tool
91-12349A2
using Disc
#2 and Flat
#7
0.018 in. to
0.027 in.
(0.460mm
to
0.686mm)
Pointer on
line mark
#1
0.030 in. to
0.050 in.
(0.762mm
to
1.27mm)
2.0:1
(15/30
teeth)
0.025 in.
(0.635mm)
With Tool
91-12349A2
using Disc
#2 and Flat
#7
0.015 in. to
0.022 in.
(0.38mm
to
0.56mm)
Pointer on
line mark
#2
0.030 in. to
0.050 in.
(0.762mm
to
1.27mm)
2.3:1
(13/30
teeth)
0.025 in.
(0.635mm)
With Tool
91-12349A2
using Disc
#2 and Flat
#7
0.018 in. to
0.023 in.
(0.46mm
to
0.58mm)
Pointer on
line mark
#4
0.030 in. to
0.050 in.
(0.762mm
to
1.27mm)
Gearcase Lubricant Capacity
All Ratios 22.5 fl. oz. (665.4ml)
Special Tools
Shift Shaft Bushing Tool 91-31107
73658
Gear Housing Cover Nut Tool 91-61069
73605
Bearing Carrier Removal Tool 91-46086A1 and
Puller Bolt 91-85716
73599
Slide Hammer Puller 91-34569A1
73655
Bearing Removal and Installation Kit 91-31229A5.
This kit contains the following tools: Pilot 91-36571;
Puller Rod 91-31229; Nut 11-24156; Puller Plate
91-29310; Mandrel 91-38628; and Driver Rod
91-37323.
70615
