90-824052R3 JUNE 2002 FUEL SYSTEMS - 3B-9

WMH 12,13,14,15,16,27

Carburetor Front View

CYLINDERS 2,4,6 CYLINDERS 1,3,5

51863

a - Idle Air Jet

b - Back Draft Vent Jet

c - Progression Jet

d - Main Jet
