90-824052R3 JUNE 2002 FUEL SYSTEMS - 3B-15
WMH 30,31,32,33,34,39 Carburetor Assembly
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 CARBURETOR
2 6 LIMITER CAP
3 6 IDLE NEEDLE/SPRING
4 3 GASKET
5 2 JET – progression air 10 1.0
6 3 JET – bowl vent 15 1.5
7 1 JET – idle air bleed 15 1.5
8 3 EMULSION TUBE, PLUG and GASKET 33 3.5
9 3 SPRING – valve return
10 2 THROTTLE LEVER
11 3 SPACER
12 3 WASHER
13 3 NUT 50 5.5
14 3 GASKET – fuel bowl
15 3 FLOAT
16 3 SCREW – float pin 10 1.0
17 3 FLOAT SHAFT
18 3 VALVE SEAT KIT 33 3.5
19 3 GASKET – valve seat
20 1 FUEL BOWL
21 3 JET – main fuel 14 1.5
22 18 SCREW – fuel bowl 26 3.0
23 6 JET – progression fuel 14 1.5
24 3 GASKET
25 3 PLUG 33 3.5
26 2 TEE FITTING (TOP/CENTER) 45 5.0
27 1 ELBOW (BOTTOM) 45 5.0
