Mariner Mercury 135 JET User Manual

90-824052R3 JUNE 2002 FUEL SYSTEMS - 3B-19
WMV 1/1A, 2/2A, 3/3A, 4/4A, 5/5A
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 TOP CARBURETOR
1
CENTER CARBURETOR 135 - WMV-1
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR 150 - WMMV-2
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR XR6/MAGNUM III
1 BOTTOM CARBURETOR WMV-3
1 TOP CARBURETOR
1 CENTER CARBURETOR 175 - WMV-4
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR 200 - WMV-5
1
1 BOTTOM CARBURETOR
1
1 TOP CARBURETOR
1 CENTER CARBURETOR 135 - WMV-1A
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR 150 - WMMV-2A
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR XR6/MAGNUM III
1 BOTTOM CARBURETOR WMV-3A
1 TOP CARBURETOR
1 CENTER CARBURETOR 175 - WMV-4A
1 BOTTOM CARBURETOR
1 TOP CARBURETOR
1 CENTER CARBURETOR 200 - WMV-5A
1 BOTTOM CARBURETOR
2 6 COVER
3 6 GASKET
4 12 SCREW 18 2.0
5 3 GASKET
2 JET–idle air vent (.036-Top/Center)(135) 14 1.5
1 JET–idle air vent (.040 - Bottom)(135) 14 1.5
1 JET–idle air vent (.034-Top)(150) 14 1.5
1 JET–idle air vent (.034 - Center)(150) PORT 14 1.5
1 JET–idle air vent (.038-Bottom)(150) 14 1.5
6
2 JET–idle air vent (.042-Top/Center)(XR6/Magnum III) 14 1.5
6
1 JET–idle air vent (.048-Bottom)(XR6/Magnum III) 14 1.5
2 JET–idle air vent (.030-Top/Center)(175) 14 1.5
1 JET–idle air vent (.038-Bottom)(175) 14 1.5
1 JET–idle air vent (.052-Top)(200) 14 1.5
1 JET–idle air vent (.028-Center)(200) 14 1.5
1 JET–idle air vent (.032-Bottom)(200) 14 1.5
– 1 CARB GASKET KIT
– 1 CARB REPAIR KIT
– 1 ENGINE GASKET SET
 = COMPONENT OF ENGINE GASKET SET
∆ = COMPONENT OF CARB GASKET SET
 = COMPONENT OF CARB REPAIR KIT
