90-824052R3 JUNE 2002 FUEL SYSTEMS - 3C-9
Fuel Pump and Fuel Filter
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 FUEL PUMP ASSEMBLY
2 1 DIAPHRAGM KIT
3 2 CHECK VALVE – rubber
4 1 GASKET – boost
5 2 DIAPHRAGM
6 1 GASKET – pulse
7 1 SPRING
8 1 CAP
9 2 CHECK VALVE
10 2 RETAINER
11 1 SPRING
12 1 CAP
13 1 GASKET – base
14 1 BASE – fuel pump
15 1 PLATE – fuel pump
16 1 ELBOW
17 2 SCREW – fuel pump 55 6.0
18 2 SCREW – fuel pump to crankcase 55 6.0
19 1 HOSE – pulse
20 1 ELBOW
21 1 TUBING
22 AR STA-STRAP – fuel tubing
23 1 FUEL CONNECTOR
24 1 SCREW 35 4.0
25 1 SEAL
26 2 TUBING
27 1 BASE – fuel filter
28 2 SCREW – fuel filter base DESIGN 1 100 11.5
29 1 BRACKET
30 1 SCREW 100 11.5
31 2 FITTING – base
32 1 FUEL FILTER ASSEMBLY
33 1 PROBE – water sensing
34 1 FUEL FILTER BASE DESIGN 2
35 1 SCREW (1/4-20 x 1-1/8″) 100 11.5
To Next Page
