90-824052R3 JUNE 2002 POWERHEAD - 4A-5
Cylinder Block and End Caps
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 CYLINDER BLOCK (135/150)
1
1 CYLINDER BLOCK (XR6/MAG. IlI )
1
1 CYLINDER BLOCK (175)
1 CYLINDER BLOCK (200)
2 6 STUD–powerhead (1-3/4 IN.)
3
2 STUD–powerhead (5-1/2 IN.)
3
2 STUD–powerhead (6-3/4 IN.)
4 2 DOWEL PIN–locating
5 2 DOWEL PIN (BEARING RACE)
6 2 GASKET–sealing
7 1 COVER–starter motor (UPPER)
8 2 SCREW (1-1/2 IN.) (HEX FLANGE) 210 17.5 23.5
9 1 COVER (LOWER)
10 2 SCREW (2 IN.)(HEX HEAD FLANGE) 210 17.5 23.5
11 1 BUSHING
12
8 SCREW (3-1/4 IN.) 150 12.5 17
12
6 SCREW (1-1/4 IN.) 150 12.5 17
13 1 UPPER END CAP ASSEMBLY
14 1 O-RING
15 1 ROLLER BEARING
16 1 OIL SEAL
17 4 SCREW (1 IN.) 150 12.5 17.0
18 1 STUD (1-7/8 IN.)
19 1 J-CLIP
20 1 PLUG–Serial Number
21 1 SPACER
22 3 WASHER
23 3 NUT 25 3.0
24 1 IDLE CONTROL
25 3 SCREW 30 3.5
26 3 WASHER
27 1 BRACKET
28 2 SCREW (3/4 IN.) 80 9.0
29 2 STUD (1 IN.)
30 1 CAP
31 1 ADJUSTING SCREW
32 1 JAM NUT
33 1 LOWER END CAP
34 1 O-RING (3-1/4 IN. I.D.)
35 2 OIL SEAL
36 4 SCREW (3/4 IN.) 80 9.0
37 4 LOCKWASHER
