90-824052R3 JUNE 2002 POWERHEAD - 4A-7
Exhaust Manifold and Exhaust Plate
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 GASKET
1 DIVIDER PLATE (S/N-0G437999 & BELOW)
2
1 DIVIDER PLATE (S/N-0G438000 & UP)
3 1 SEAL
4 4 J-CLAMP
5 20 SCREW 200 16.5 22.5
6 1 FITTING
7 1 FITTING (90°)
8 1 HOSE (23-1/2 IN.)
9 2 STA-STRAP
10 1 COVER–relief valve
11 4 SCREW (1-1/4 IN.) 150 12.5 17.0
12 2 GASKET
13 1 SCREW (3/4 IN.) 25 3.0
14 1 WASHER
15 1 DIAPHRAGM
16 1 WATER DEFLECTOR
17 1 PLATE
18 1 SPRING
19 1 WASHER
20 1 POPPET
21 1 GROMMET
22 1 CARRIER
23 1 GASKET
24 1 EXHAUST PLATE
25 1 CONNECTOR (STRAIGHT)
26 2 DOWEL PIN
27 1 SEAL
28 1 BRACKET
29 8 SCREW (1/2 IN.)
30 6 WASHER
31 6 NUT 240 20 27.0
32 1 BUSHING
33 1 GROMMET
34 1 GROMMET
35 1 SCREW (1-1/4 IN.) 300 25 34.0
36 1 SCREW (2-1/2 IN.) 300 25 34.0
37 3 SCREW (3-1/2 IN.) 50 68.0
38 1 FRONT BRACKET ASSEMBLY
4 SCREW (1/2 IN.)
39
4 SCREW (5/8 IN.) 216 18 24.5
40 4 WASHER (Use with 5/8 IN. ref. #39)
41 4 WASHER
42 4 GROMMET
43 1 REAR BRACKET ASSEMBLY
