90-824052R3 JUNE 2002 POWERHEAD - 4A-9
Reed Block and Cylinder Head
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 2 CYLINDER HEAD 135/150
2 2
GASKET
1 2 CYLINDER HEAD XR6/ Magnum III
2 2 GASKET 175
1 2 CYLINDER HEAD 200
2 2 GASKET
3 24 SCREW (2 IN.) 30 lb. ft. (40.5 N·m);
Then Turn Additional
90°
4 4 DOWEL PIN
5 2 GASKET
6 2 COVER
7 2 THERMOSTAT
8 4 SCREW (1 IN.) 200 16.5 22.5
9 1 ELBOW
10 1 TEMPERATURE SENDER (STBD.)
11 1 THERMAL AIR VALVE
12 1 HOSE (12-3/4 IN.)
13 1 FITTING
14 10 STA-STRAP
15 1 HOSE (11-1/2 IN.)
16 1 T-FITTING
17 1 TEMPERATURE SENSOR (PORT) (2-WIRE)
18 2 RETAINER
19 2 SCREW 200 16.5 22.5
20 1 HOSE (7-1/2 IN.)
21 1 ADAPTOR PLATE
22 8 SCREW 105 9.0 12.0
23 1 GASKET
24 6 REED BLOCK
25 1 J-CLAMP
26 1 CLIP
27 1 C-WASHER
28 1 SCREW 85 7.0 9.5
29 6 SCREW (7/8 IN.) 105 9.0 12.0
30 6 SCREW (1-1/8 IN.) 80 6.5 9.0
To Next Page
