90-824052R3 JUNE 2002 LOWER UNIT - 6A-7
Gear Housing (Driveshaft) (Standard Rotation)
(S/N-0G437999 & BELOW)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 GEAR HOUSING
2 1 CONNECTOR ASSEMBLY
3 1 TUBING
4 1 CONNECTOR
5 2 DOWEL PIN
6
1 STUD (3-1/8 IN.) (LONG)
6
1 STUD (3-11/16 IN.) (X-LONG)
7 2 STUD (2-1/16 IN.)
8 1 STUD (3-3/8 IN.)
9 2 STUD (3-1/8 IN.)
10 1 FILLER BLOCK
11 1 ROLLER BEARING
12 2 ANODE
13 1 SCREW
14 1 NUT 60 5.0 7.0
15
1 PINION GEAR (Part of 43-44102A7 or 43-44104A8
15
1 PINION GEAR (Part of 43-16294A2)(HIGH ALTITUDE – 2.3:1)
16 1 WASHER (NOT USED W/HIGH ALTITUDE)
17
1
NUT
Incl
u
ded
With
Forward
Gear
Set
17
1
NUT (HIGH ALTITUDE)
18 AR SHIM SET
19 1 SCREW–drain & fill (MAGNETIC) 55 6.0
20 2 WASHER
21 1 SCREW–vent 55 6.0
22 1 STA–STRAP
23 1 SHIFT SHAFT
24 1 O-RING
25 1 BUSHING ASSEMBLY 30 40.5
26 1 OIL SEAL
27 1 WASHER–rubber
1 DRIVE SHAFT (LONG)
2
8
1 DRIVE SHAFT (X-LONG)
28
1 DRIVE SHAFT (HIGH ALTITUDE)
29 1 ROLLER BEARING ASSEMBLY
30 1 CUP-Tapered
31 1 RETAINER 100 135
32 1 WATER PUMP BASE
33 1 GASKET
34 1 O-RING
35 1 OIL SEAL
36 1 OIL SEAL
37 1 GASKET–lower
38 1 GASKET–upper
39 1 FACE PLATE
40 1 WATER PUMP BODY ASSEMBLY
41 1 INSERT
42 1 SEAL–rubber
43 1 lMPELLER
44 1 KEY
45 1 SCREW (2-1/4 IN.) 50 5.5
46 2 WASHER
47 2 NUT 50 5.5
48 1 WASHER
49 1 NUT 50 5.5
50 1 SLEEVE
