90-824052R3 JUNE 2002 LOWER UNIT - 6A-15
Gear Housing (Driveshaft) (Standard Rotation)
(Torque Master) (Pro Max/Super Magnum Models)
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 GEAR HOUSING
2 1 CONNECTOR ASSEMBLY
3 1 TUBING
4 1 CONNECTOR
5 2 DOWEL PIN
1 STUD (3-1/8 IN.)
6 2 STUD (2-1/16 IN.)
7 1 STUD (3-3/8 IN.)
8 2 STUD (3-1/8 IN.)
9 1 FILLER BLOCK
10 1 ROLLER BEARING
11 2 ANODE
12 1 SCREW
13 1 NUT 60 5 7.0
14 1 PINION GEAR (Part of 43-44102A7)
15 1 WASHER
16 1 PINION NUT Included With Forward Gear Set 85 115
17 AR SHIM SET
18 1 SCREW–drain (MAGNETIC) 55 6.0
19 2 WASHER
20 1 SCREW–grease filler 55 6.0
21 1 SHIFT SHAFT
22 1 O-RING
23 1 BUSHING ASSEMBLY 50 68
24 1 OIL SEAL
25 1 WASHER–rubber
26 1 DRIVE SHAFT
27 1 ROLLER BEARING ASSEMBLY
28 1 CUP-Tapered
29 1 RETAINER 100 135
30 1 WATER PUMP BASE
31 1 GASKET
32 1 O-RING
33 1 OIL SEAL
34 1 OIL SEAL
35 1 GASKET–lower
36 1 GASKET–upper
37 1 FACE PLATE
38 1 WATER PUMP BODY ASSEMBLY
39 1 INSERT
40 1 SEAL–rubber
41 1 lMPELLER
42 1 KEY
43 1 SCREW (2-1/4 IN.) 50 5.5
44 2 WASHER
45 2 NUT 50 5.5
46 1 WASHER
47 1 NUT 50 5.5
48 1 SLEEVE
