90-824052R3 JUNE 2002 LOWER UNIT - 6A-17

Gear Housing (Prop Shaft) (Standard Rotation)

(Torque Master) (Pro Max/Super Magnum Models)

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 1 GEAR HOUSING

49 1 CAM FOLLOWER

50 1 SHIFT CAM

51 1 ROD ASSEMBLY

52 1 PIN

53 1 SPRING

54 AR WASHER

55 AR SHIM (.002–3–5–10)

56 1 TAPERED ROLLER BEARING

57 1 GEAR SET

58 2 ROLLER BEARING

59 1 CLUTCH

60 1 CROSS PIN

61 2 DETENT PIN

62 2 SPRING

63 1 PROPELLER SHAFT

64 1 REVERSE GEAR

65 1 THRUST SPACER (NOT USED W/HIGH ALTITUDE)

66 1 THRUST RING

67 1 BALL BEARING

68 1 O-RING

69 1 BEARING CARRIER ASSEMBLY

70 1 ROLLER BEARING

71 1 RETAINING RING

72 2 OIL SEAL

73 1 KEY

74 1 TAB WASHER

75 1 COVER NUT 250 339

76 1 THRUST HUB

77 1 LOCKWASHER

78 1 SPLINED WASHER

79 1 PROPELLER NUT 55 74.5

80 1 TAB WASHER

81 1 ANODIC PLATE

82 1 SCREW 25 34.0

83 2 NUT 65 88

84 1 SCREW 35 47.5

85 2 WASHER
