90-824052R3 JUNE 2002 LOWER UNIT - 6A-23

Gear Housing (Prop Shaft) (Standard Rotation)

(Sportmaster)

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 1 GEAR HOUSING (WITH TORQUE TAB) BASIC

1 1

GEAR HOUSING (WITHOUT TORQUE TAB)

50 1 CAM FOLLOWER

51 1 SHIFT CAM

52 1 ROD

53 1 PIN

54 2 SPRING

55 2 WASHER

56 AR SHIM SET

57 1 TAPERED ROLLER BEARING

58 1 FORWARD GEAR SET (Includes Pinion)

59 1 ROLLER BEARING

60 1 RATCHET

61 2 DETENT PIN

62 1 CROSS PIN

63 2 SPRING

64 1 PROPELLER SHAFT

65 1 REVERSE GEAR

66 1 THRUST RING

67 1 BALL BEARING

68 1 THRUST RING

69 1 O RING

70 1 BEARING CARRIER

71 1 ROLLER BEARING

72 1 SNAP RING

73 2 OIL SEAL

74 1 MAGNETIC DRAIN SCREW

75 1 SEALING WASHER

76 1 KEY

77 1 TAB WASHER

78 1 COVER NUT

250 339

79 1 THRUST HUB

80 1 LOCKWASHER

81 1 WASHER

82 1 PROPELLER NUT

55 74.5

83 1 TAB WASHER

84 1 SCREW

25 34.0

85 2 WASHER

86 2 NUT

65 88.0

87 1 SCREW

35 47.5

1 ANODIC PLATE
