90-824052R3 JUNE 2002 ELECTRICAL - 2A-5

Flywheel/Starter Motor

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 1 FLYWHEEL COVER ASSEMBLY

2 1 MARKER

3 2 SCREW

4 2 WASHER

5 1 PLUG

6 1 PLUG

7 1 NUT 120 163

8 1 WASHER

9 1 FLYWHEEL

10 1 STATOR

11 4 SCREW 50 5.5

12 4 WASHER

13 1 TRIGGER PLATE ASSEMBLY

14 1 STARTER MOTOR

15 2 COLLAR

16 2 RUBBER STOP

17 1 SCREW 80 9.0

18 1 WIRE ASSEMBLY (BLACK)

19 1 WIRE ASSEMBLY (BLACK)

20 1 LOCKWASHER

21 1 NUT 60 7.0
