90-824052R3 JUNE 2002 LOWER UNIT - 6B-11

Gear Housing (Prop Shaft) (Counter Rotation)

(S/N-0G437999 & BELOW)

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 GEAR HOUSING (BASIC–BLACK)

1 GEAR HOUSING (BASIC–GRAY)

67 1 ROLLER BEARING

68 1 THRUST RING

69 1 O RING

70 1 BEARING ADAPTOR

71 1 ROLLER BEARING

72 2 THRUST WASHER

73 2 THRUST BEARING

74 1 PROPELLER SHAFT

75 1 BEARING CARRIER ASSEMBLY

76 1 ROLLER BEARING

77 1 OIL SEAL (INSIDE)

78 1 OIL SEAL (OUTSIDE)

79 1 KEY

80 1 TAB WASHER

81 1 COVER NUT 210 285

82 1 TRIM TAB

83 1 SCREW 40 54.0

84 1 SCREW (.375-16 x 1) 55 75.0

85 2 WASHER

86 2 NUT 55 75.0

87 1 THRUST HUB

88 1

LOCKWASHER These replacement parts

89 1 WASHER ARE NOT included with

90 1 PROPELLER NUT Complete 55 75.0

91 1 TAB WASHER Gear Housing replacement
