6C-2 - LOWER UNIT 90-824052R3 JUNE 2002

Bearing Removal and Installation Kit 91-31229A5.

This kit contains the following tools: Pilot 91-36571;

Puller Rod 91-31229; Nut 11-24156; Puller Plate

91-29310; Mandrel 91-38628; and Driver Rod

91-37323.

70615

Mandrel 91-38628

74193

Driver Rod 91-37323

74184

Mandrel 91-31106

Shift Shaft Bushing Tool 91-31107

73658

Oil Seal Driver 91-31108

73651
