90-824052R3 JUNE 2002 LOWER UNIT - 6E-47

9. After first use, retighten propeller nut and again

secure with tab washer (Steps 7 and 8, preced-

ing). Propeller should be checked periodically for

tightness, particularly if a stainless steel propeller

is used.

51916

a - Continuity Washer (If Equipped)

b - Rear Thrust Hub

c - Tab Washer

d - Propeller Nut

Important 1 B15
