Item Notes Description
Local Endpoint IP Address, Remote Endpoint IP Address and Static Key
will be displayed.
Local Endpoint IP
Address
Mandatory field.
Specify the virtual Local Endpoint IP Address of this OpenVPN
router.
Value Range: The IP format is 10.8.0.x, the range of x is 1 - 254.
Note – Local Endpoint IP Address will be available only
when
Static Key
is chosen in
Authorization Mode
.
Remote
Endpoint IP
Address
Mandatory field.
Specify the virtual Remote Endpoint IP Address of the peer OpenVPN
router.
Value Range: The IP format is 10.8.0.x, the range of x is 1 - 254.
Note – Remote Endpoint IP Address will be available only
when
Static Key
is chosen in
Authorization Mode
.
Static Key
Mandatory field.
Specify the Static Key.
Note
–
Static Key
will be available only when
Static Key
is
chosen in
Authorization Mode
.
Encryption Cipher Default setting:
Blowfish
Specify the Encryption Cipher.
It can be Blowfish/AES-256/AES-192/AES-128/None.
Hash Algorithm Default setting:
SHA-1
Specify the Hash Algorithm.
Available settings: SHA-1, MD5, MD4, SHA2-256, SHA2-512, None or
Disable
LZO Compression Default setting:
Adaptive
Specify the LZO Compression scheme.
Available settings: Adaptive, YES, NO or Default
Persis Key
Optional setting.
Enabled by default.
Check

Enable
to activate the Persis Key function.
Persis Tun
Optional setting.
Enabled by default.
Check

Enable
to activate the Persis TUN function.
Advanced
Configuration
Button
Click the
Edit
button to specify the Advanced Configuration setting
for the
OpenVPN serve in the
Advanced Configuration section.
Tunnel
Disabled by default.
Check

Enable
to activate this OpenVPN tunnel.
Save
Button
Click
Save
to save the settings.
Undo
Button
Click
Undo
to cancel the changes.
Back
Button
Click
Back
to return to last page.
Table 153 – OpenVPN Client Configuration
When Advanced Configuration is selected, the OpenVPN Client Advanced Configuration section is displayed.
