Item Value setting Description
TCP/UDP
Write(bytes)
System data. Displays the TCP/UDP Write Bytes of OpenVPN Client.
Connection
Conn. Time System data. Displays the connection time for the corresponding OpenVPN
tunnel.
Conn. Status System data. Displays the connection status of the corresponding OpenVPN
tunnel.
The status can be Connected, or Disconnected.
Table 17 – OpenVPN Client Status
L2TP Server/Client Status
LT2TP Server/Client Status shows the configuration for establishing LT2TP tunnel and current connection status.
Figure 26 – L2TP Server Status
Item Value setting Description
User Name N/A Displays the login name of the user used for the connection.
Remote IP System data. Displays the public IP address (the WAN IP address) of the
connected L2TP client.
Remote Virtual IP System data. Displays the IP address assigned to the connected L2TP client.
Remote Call ID System data. Displays the L2TP client Call ID.
Conn. Time System data. Displays the connection time for the L2TP tunnel.
Status System data. Displays the Status of each of the L2TP client connection. The
status displays Connected, Disconnect, Connecting
Edit Button Click on Edit Button to change L2TP server setting, web-based
utility will take you to the L2TP server page. (Security > VPN >
L2TP tab)
Table 18 – L2TP Server Status
Figure 27 – L2TP Client Status
Item Value setting Description
Client Name System data. Displays Name for the L2TP Client specified.
Interface System data. Displays the WAN interface with which the gateway will use to
request PPTP tunnelling connection to the PPTP server.
Virtual IP System data. Displays the IP address assigned by Virtual IP server of L2TP
server.
