Object 2405.1: Deadband [on/off]
Object name
C3Plus.DeadBandCompensation_Ch0_Type
Object No. 2405.1 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
INT
Unit
1
Minimum value
n/a
Maximum value
n/a
Remark:
Type of deadband compensation
Type=0 block off (input=output)
Type=1 deadband compensation with constantly zero in the deadband
Type=2 deadband compensation with straight line in the deadband
Objects of the other conditioning chains: 24x5.1
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 2405.2: Deadband A-side
Object name
C3Plus.DeadBandCompensation_Ch0_A_Side
Object No. 2405.2 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
INT
Unit
°/oo
Minimum value
0 °/oo
Maximum value
1,000 °/oo
Remark:
Threshold value on A side
Objects of the other conditioning chains: 24x5.2
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2405.3: Deadband B-side
Object name
C3Plus.DeadBandCompensation_Ch0_B_Side
Object No. 2405.3 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
INT
Unit
°/oo
Minimum value
0 °/oo
Maximum value
1,000 °/oo
Remark:
Threshold value on B side
Objects of the other conditioning chains: 24x5.3
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
