Parker Compax3 Fluid T40

Parker EME
Setting up Compax3
192-121102 N04 June 2008 135
Object 2401.6: Inversion [on/off]
Object name
C3Plus.DirectionDependentGain_Ch0_InvertType
Object No. 2401.6 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
BOOL
Unit
n/a
Minimum value
n/a
Maximum value
n/a
Remark:
Type=0 no inversion
Type<>0 Signal is inverted (+<=>-)
Objects of the other conditioning chains: 24x1.6
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 2402.1: Pressure Compensation [on/off]
Object name
C3Plus.PressureCompensation_Ch0_Type
Object No. 2402.1 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
INT
Unit
n/a
Minimum value
n/a
Maximum value
n/a
Remark:
Type=1 Differential pressure at side A is compensated
Type=1 Differential pressure at side A is compensated
Objects of the other conditioning chains: 24x2.1
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
Object 2403.1: Characteristic flow [on/off]
Object name
C3Plus.SignalFlowCharacteristic_Ch0_Type
Object No. 2403.1 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
INT
Unit
n/a
Minimum value
n/a
Maximum value
n/a
Remark:
Type=0 characeristic compensation is switched off
Type=1 characteristic commpensation is switched on: when the limits of
the characteristic line are exceeded, interpolation is continued with
constant slope
Type=2 characteristic compensation is switched on: when the limits of
the characteristic line are exceeded, the output value is limited to the
limit value of the characteristic line.
Objects of the other conditioning chains: 24x3.1
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I16
