Parker Compax3 Fluid T40

Setting up Compax3 C3F_T40
134 192-121102 N04 June 2008
Object 2401.5: Gain factor negative
Object name
C3Plus.DirectionDependentGain_Ch0_Factor_negative
Object No. 2401.5 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
1
Minimum value
n/a
Maximum value
n/a
Remark:
Gain factor for negative input values
Objects of the other conditioning chains: 24x1.5
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2401.7: Gain positive direction (Force-/Pressure- control)
Object name
C3.DirectionDependentGain_Ch0_Factor_positiv_Pressure
Object No. 2401.7 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
no
CodeSys format:
Unit
1
Minimum value
n/a
Maximum value
n/a
Remark:
Gain factor for positive input values (with pressure/force control)
Objects of the other conditioning chains: 24x1.7
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2401.8: Gain negative direction (Force-/Pressure- control)
Object name
C3.DirectionDependentGain_Ch0_Factor_negative_Pressur
e
Object No. 2401.8 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
no
CodeSys format:
Unit
1
Minimum value
n/a
Maximum value
n/a
Remark:
Gain factor for negative input values (with pressure/force control)
Objects of the other conditioning chains: 24x1.8
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
