Parker Compax3 Fluid T40

Parker EME
Setting up Compax3
192-121102 N04 June 2008 133
Object 2400.6: Output Offset
Object name
C3Plus.OutputConditioningChain_Ch0_Output_Offset
Object No. 2400.6 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
REAL
Unit
%
Minimum value
-100 %
Maximum value
100 %
Remark:
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2400.7: Replacement value (inactive Chain 0)
Object name
C3Plus.OutputConditioningChain_Ch0_Input_DefaultValue
Object No. 2400.7 HEDA-channel
no
Access:
Read/write
Valid after:
VP
CodeSys object:
yes
CodeSys format:
REAL
Unit
%
Minimum value
-100 %
Maximum value
100 %
Remark:
Replacement value on the input of the chain, if the correspondiing
controller (position or force controller) is not operating.
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
Object 2401.4: Gain factor positive
Object name
C3Plus.DirectionDependentGain_Ch0_Factor_positive
Object No. 2401.4 HEDA-channel
no
Access:
Read/write
Valid after:
Immediately
CodeSys object:
yes
CodeSys format:
REAL
Unit
1
Minimum value
n/a
Maximum value
n/a
Remark:
Gain factor for positive input values
Objects of the other conditioning chains: 24x1.4
(x = 0,1,2,3 = Conditioning Chain No.)
CAN No.
-
PD object:
no
Profibus-No. (PNU)
-
Bus format:
I32
