Parker EME
Motion control
192-121102 N04 June 2008 217
Here you can enter:
Axis name
Number of interpolation points to be calculated per curve,
Signal source ”Encoder A/B 5V” and
"Dwell-to-dwell motion law".
Do not change the default settings:
180 points and
the ”modified sine line according to Neklutin” (russian mathematician)
At first the display is empty; the motion sequence can be entered.
This is made via the menu: File: New sequence.
In the dialog box you can select the the axis name of your choice, here ”axis”
The display looks as follows:
