Parker EME
Motion control
192-121102 N04 June 2008 255
Example: Change-over function over several curve cycles
M
S
Sa
ST
MT
0
MS
ME
SS
1
SS: Slave synchronization position
Sa: current slave position before start of curve
ME: Master coupling position = 60°
MS: Master synchronized position = 700°
MT: Master clock distance = 360°
ST: Slave clock distance
1: The slave setpoint value is reset at this position in the display.
