Parker Compax3 Fluid T40

Communication
C3F_T40
410 192-121102 N04 June 2008
The following objects are transmitted:
TRANSMIT (send) RECEIVE RECEIVE
Mapping
Table
Source Objects Target
1 S1 C3Array.Col01Row01 (1901.1) M C3Array.Col01Row01 (1901.1)
2 S1 C3Plus.DeviceState_Statusword1 (1000.3) M C3Array.Col03Row01 (1903.1)
3 S1 C3Plus.ProfileGenerators_SG1Position (2000.1) M
S2
C3Array.Col01Row02 (1902.1)
C3Plus.HEDA_SignalProcessing_Input
(3920.1)
4 S2 C3Plus.PositionController_DemandValue
(2200.1)
S3 C3Plus.HEDA_SignalProcessing_Input
(3920.1)
5 M C3Plus.ProfilGenerators_PG2Position (2000.2) S1
S2
S3
C3Plus.HEDA_SignalProcessing_Input
(3920.1)
C3Array.Col01Row05 (1901.5)
C3Array.Col01Row05 (1901.5)
6 M C3Plus.DeviceControl_Controlword1 (1100.3) S1 C3Plus.DeviceControl_Controlword1 (1100.3)
7 M C3Array.Col06Row01 (1906.1) S1 C3Array.Col06Row01 (1906.1)
M: Master
S1, S2, S3: Slave 1 ... 3
Word form for the objects to be transmitted in the internet
http://apps.parker.com/euro_emd/EME/
downloads/compax3/HEDA-
Formulare/communications-table.doc.
