Compax3 - Objects C3F_T40
418 192-121102 N04 June 2008
Bus object No. Object name Object PNU CAN No. Format PD Valid
beginning
I20 I21 / I22
950.1 C3.FBI_RxPD_Mapping_Object_1 1. Object of the setpoint PZD
(Profibus)
915.0
U16 no Immediat
ely
X -
950.2 C3.FBI_RxPD_Mapping_Object_2 2. object of the Setpoint value PZD 915.1
U16 no Immediat
ely
X -
950.3 C3.FBI_RxPD_Mapping_Object_3 3. object of the Setpoint value PZD 915.2
U16 no Immediat
ely
X -
950.4 C3.FBI_RxPD_Mapping_Object_4 4. object of the Setpoint value PZD 915.3
U16 no Immediat
ely
X -
950.5 C3.FBI_RxPD_Mapping_Object_5 5. object of the Setpoint value PZD 915.4
U16 no Immediat
ely
X -
950.6 C3.FBI_RxPD_Mapping_Object_6 6. object of the Setpoint value PZD 915.5
U16 no Immediat
ely
X -
950.7 C3.FBI_RxPD_Mapping_Object_7 7. object of the Setpoint value PZD 915.6
U16 no Immediat
ely
X -
950.8 C3.FBI_RxPD_Mapping_Object_8 8. object of the Setpoint value PZD 915.7
U16 no Immediat
ely
X -
3921.1 C3.FBI_SignalProcessing0_Input Interpolation input CanSync,
PowerLink
0x2050 I32 yes Immediat
ely
- X
951.1 C3.FBI_TxPD_Mapping_Object_1 1. object of actual value PZD 916.0
U16 no Immediat
ely
X -
951.2 C3.FBI_TxPD_Mapping_Object_2 2. object of actual value PZD 916.1
U16 no Immediat
ely
X -
951.3 C3.FBI_TxPD_Mapping_Object_3 3. object of actual value PZD 916.2
U16 no Immediat
ely
X -
951.4 C3.FBI_TxPD_Mapping_Object_4 4. object of actual value PZD 916.3
U16 no Immediat
ely
X -
951.5 C3.FBI_TxPD_Mapping_Object_5 5. object of actual value PZD 916.4
U16 no Immediat
ely
X -
951.6 C3.FBI_TxPD_Mapping_Object_6 6. object of actual value PZD 916.5
U16 no Immediat
ely
X -
951.7 C3.FBI_TxPD_Mapping_Object_7 7. object of actual value PZD 916.6
U16 no Immediat
ely
X -
951.8 C3.FBI_TxPD_Mapping_Object_8 8. object of actual value PZD 916.7
U16 no Immediat
ely
X -
2050.10 C3.FeedForward_2_Accel_FFW Acceleration feedforward (A2)
C4_3 no VP - -
2050.9 C3.FeedForward_2_Speed_FFW Speed feedforward (A2)
C4_3 no VP - -
2050.8 C3.FeedForward_2_Valve Valve feedforward auxiliary axis
U16 no VP - -
2010.24 C3.FeedForward_Speed_FFW Acceleration feedforward (A1)
C4_3 no VP - -
2010.23 C3.FeedForward_Speed_FFW Speed feedforward (A1)
C4_3 no VP - -
2010.21 C3.FeedForward_Valve Valve feedforward
U16 no VP - -
2011.5 C3.FeedForwardExternal_FilterAccel_us Filter time constant ext. Acceleration
U16 no VP - -
2011.4 C3.FeedForwardExternal_FilterSpeed_us Filter time constant ext. Velocity
U16 no VP - -
1141.8 C3.GEAR_actual_master_speed Master speed for Gearing
C4_3 no - - -
1141.7 C3.GEAR_actual_masterposition Position input value for Gearing
0x2058 C4_3 no - - -
696.1 C3.HydraulicPower_Axis1 Control signal main axis
I32 no - - -
696.2 C3.HydraulicPower_Axis2 Control signal auxiliary axis
I32 no - - -
696.3 C3.HydraulicPower_Sum Sum of the hydraulic corner power
I32 no - - -
402.2 C3.Limit_SpeedNegative Maximum permissible negative speed 318 0x200A I16 no VP - -
402.1 C3.Limit_SpeedPositive Maximum permissible positive speed 317 0x2009 I16 no VP - -
425.2 C3.LimitForcePressure_FollowingErrorTime Trigger time for event "Control
deviation of force controller"
I16 no Immediat
ely
- -
425.1 C3.LimitForcePressure_FollowingErrorWindow Max. control deviation of force
controller
C4_3 no VP - -
425.6 C3.LimitForcePressure_ForceReachedAux Force of auxiliary axis in the control
window
BOOL no - - -
425.5 C3.LimitForcePressure_ForceReachedMain Force of main axis in the control
window
BOOL no - - -
425.3 C3.LimitForcePressure_MaxForce Maximum force
I32 no Immediat
ely
- -
425.4 C3.LimitForcePressure_Window Window for "Force achieved"
I32 no VP - -
425.7 C3.LimitForcePressure_WindowTime Trigger time for message "Force
achieved"
U16 no Immediat
ely
- -
410.3 C3.LimitPosition_Negative negative end limit 322 0x607D.1 C4_3 no Immediat
ely
- -
410.2 C3.LimitPosition_Positive positive end limit 321 0x607D.2 C4_3 no Immediat
ely
- -
3310.1 C3.Multiturnemulation_Status Status of the Multiturn emulation
I16 no - - -
200.10 C3.NormFactorY2_ActualValue2_Y2 Normalization factor for 1000.14
V2 no Immediat
ely
X X
200.7 C3.NormFactorY2_ActualValue3 Normalization factor for 1000.8 355.7 0x2020.7 V2 no Immediat
ely
X X
200.8 C3.NormFactorY2_ActualValue4 Normalization factor for 1000.9 355.8 0x2020.8 V2 no Immediat
ely
X X
200.5 C3.NormFactorY2_Array_Col2 Scaling factor recipe arrays column 2 355.5 0x2020.5 V2 no Immediat
ely
X X
200.9 C3.NormFactorY2_DemandValue2_Y2 Normalization factor for 1100.14
1100.14
V2 no Immediat
ely
X X
200.4 C3.NormFactorY2_DemandValue3 Normalization factor for 1100.8 355.4 0x2020.4 V2 no Immediat
ely
X X
200.6 C3.NormFactorY2_DemandValue4 Normalization factor for 1100.9 355.6 0x2020.6 V2 no Immediat
ely
X X
200.1 C3.NormFactorY2_Speed Scaling factor for Y2 speeds 355.1 0x2020.1 V2 no Immediat
ely
X X
200.3 C3.NormFactorY2_Voltage Scaling factor for Y2 voltages 355.3 0x2020.3 V2 no Immediat
ely
X X
201.7 C3.NormFactorY4_ActualValue1 Normalization factor for 1000.6 356.7 0x2021.7 V2 no Immediat
ely
X X
201.8 C3.NormFactorY4_ActualValue2 Normalization factor for 1000.7 356.8 0x2021.8 V2 no Immediat
ely
X X
201.13 C3.NormFactorY4_ActualValue8 Normalization factor for 1000.13 356.13 0x2021.13 V2 no Immediat
ely
X X
201.4 C3.NormFactorY4_Array_Col1 Scaling factor recipe arrays column 1 356.4 0x2021.4 V2 no Immediat
ely
X X
201.5 C3.NormFactorY4_DemandValue1 Normalization factor for 1100.6 356.5 0x2021.5 V2 no Immediat
ely
X X
