Compax3 - Objects C3F_T40
422 192-121102 N04 June 2008
Bus object No. Object name Object PNU CAN No. Format PD Valid
beginning
I20 I21 / I22
1910.6 C3Array.Indirect_Col06 Indirect table access Column 6 186 0x2316 I32 yes Immediat
ely
- -
1910.7 C3Array.Indirect_Col07 Indirect table access Column 7 187 0x2317 I32 yes Immediat
ely
- -
1910.8 C3Array.Indirect_Col08 Indirect table access Column 8 188 0x2318 I32 yes Immediat
ely
- -
1910.9 C3Array.Indirect_Col09 Indirect table access Column 9 189 0x2319 I32 yes Immediat
ely
- -
1900.1 C3Array.Pointer_Row Pointer to table row 180 0x2300 U16 yes Immediat
ely
- -
3730.3 C3Cam.ControlledSwitch00_PositionOff switch-off position of cam 509.1 0x2409.1 C4_3 no VP - -
3730.2 C3Cam.ControlledSwitch00_PositionOn switch-on position of cam 508.1 0x2408.1 C4_3 no VP - -
3730.1 C3Cam.ControlledSwitch00_Source source of cam 507.1 0x2407.1 I16 no VP - -
3730.5 C3Cam.ControlledSwitch00_TimeOff switch-off anticipation of cam 511.1 0x240B.1 I16 no Immediat
ely
- -
3730.4 C3Cam.ControlledSwitch00_TimeOn switch-on anticipation of cam 510.1 0x240A.1 I16 no Immediat
ely
- -
3701.2 C3Cam.ControlledSwitches_Enable0 enable of cam group 0 501.2 0x2401.2 U16 no Immediat
ely
- -
3701.4 C3Cam.ControlledSwitches_Enable1 enable of cam group 1 501.4 0x2401.4 U16 no Immediat
ely
- -
3701.6 C3Cam.ControlledSwitches_NumberPerCycle Number of cams in one cycle
U16 no Immediat
ely
- -
3701.3 C3Cam.ControlledSwitches_Output0 output of cam group 0 205/501.3 0x2401.3 U16 yes Immediat
ely
- -
3701.5 C3Cam.ControlledSwitches_Output1 output of cam group 1 206/501.5 0x2401.5 U16 yes Immediat
ely
- -
3700.2 C3Cam.ControlledSwitchesFast_Enable enable fast cams 500.2 0x2400.2 U16 no Immediat
ely
- -
3700.3 C3Cam.ControlledSwitchesFast_Output output for fast cams 204/500.3 0x2400.3 U16 yes Immediat
ely
- -
3705.1 C3Cam.ControlledSwitchesHysteresis_ActualPositi
on
Hysteresis for cam switching
mechanism, source "current position"
C4_3 no VP - -
3705.5 C3Cam.ControlledSwitchesHysteresis_Masterposit
ion
Hysteresis for cam switching
mechanism, source "master position"
C4_3 no VP - -
3710.3 C3Cam.ControlledSwitchFast0_PositionOff switch-off position for fast cam 504.1 0x2404.1 C4_3 no VP - -
3710.2 C3Cam.ControlledSwitchFast0_PositionOn switch-on position for fast cam 503.1 0x2403.1 C4_3 no VP - -
3710.1 C3Cam.ControlledSwitchFast0_Source source of fast cam 502.1 0x2402.1 I16 no VP - -
3710.5 C3Cam.ControlledSwitchFast0_TimeOff switch-off anticipation of fast cam 506.1 0x2406.1 I16 no Immediat
ely
- -
3710.4 C3Cam.ControlledSwitchFast0_TimeOn switch-on anticipation of fast cam 505.1 0x2405.1 I16 no Immediat
ely
- -
3022.1 C3Cam.Manipulation_OffsetMasterposition Master position offset
C4_3 no Immediat
ely
- -
3022.6 C3Cam.Manipulation_OffsetMasterposition_Units Offset Master position
C4_3 no Immediat
ely
- -
3022.3 C3Cam.Manipulation_ScalefactorMasterGlobal Global scaling factor for the master
speed
C4_3 no Immediat
ely
- -
3021.10 C3Cam.SignalSource_InputAdditional CAM Master position
C4_3 yes Immediat
ely
- -
3021.2 C3Cam.SignalSource_Position Status of position of selected master
signal source
C4_3 yes - - -
3021.1 C3Cam.SignalSource_Select Source of master position
U16 no Immediat
ely
- -
3031.4 C3Cam.StatusData_ActualCurve Current curve number
I16 no - - -
3030.7 C3Cam.StatusMaster_Enable Status: Enable of master acquisition
U16 no - - -
3030.17 C3Cam.StatusMaster_EnableCam Status: Enable of cam input
U16 no - - -
3030.13 C3Cam.StatusMaster_InputSum Free running master position after MP
enable
C4_3 yes - - -
3030.12 C3Cam.StatusMaster_PhasingSum Added up position sum of the master-
side phasing
C4_3 no - - -
3030.1 C3Cam.StatusMaster_Position Reset master position 207 0x2410 C4_3 yes - - -
3030.24 C3Cam.StatusMaster_PositionCamUnits Master position at the beginning of
the curve
C4_3 yes - - -
3030.22 C3Cam.StatusMaster_SpeedUnits Master speed [Units/s]
C4_3 no - - -
3032.4 C3Cam.StatusOutput_AbsolutePositionGreat Slave position (free running)
C4_3 yes - - -
3032.24 C3Cam.StatusOutput_CurvePositionUnits End of curve 208 0x2411 C4_3 yes - - -
3032.1 C3Cam.StatusOutput_Position Slave position
C4_3 yes - - -
172.3 C3Plus.AnalogInput0_FilterCoefficient Filter X1:IN0
I32 no VP - -
172.2 C3Plus.AnalogInput0_Gain Gain X1:IN0
C4_3 no VP - -
172.9 C3Plus.AnalogInput0_LowerLimit Lower limit value X1:IN0
I32 no Immediat
ely
- -
172.11 C3Plus.AnalogInput0_Offset_normed Offset X1:IN0
C4_3 no Immediat
ely
- -
172.10 C3Plus.AnalogInput0_UpperLimit upper limit value X1:IN0
I32 no Immediat
ely
- -
173.3 C3Plus.AnalogInput1_FilterCoefficient Filter X1:IN1
I32 no VP - -
173.2 C3Plus.AnalogInput1_Gain Gain X1:IN1
C4_3 no VP - -
173.9 C3Plus.AnalogInput1_LowerLimit Lower limit value X1:IN1
I32 no Immediat
ely
- -
173.11 C3Plus.AnalogInput1_Offset_normed Offset X1:IN1
C4_3 no Immediat
ely
- -
173.10 C3Plus.AnalogInput1_UpperLimit Upper limit value X1:IN1
I32 no Immediat
ely
- -
174.3 C3Plus.AnalogInput2_FilterCoefficient Filter X1:IN2
I32 no VP - -
174.2 C3Plus.AnalogInput2_Gain Gain X1:IN2
C4_3 no VP - -
174.9 C3Plus.AnalogInput2_LowerLimit Lower limit value X1:IN2
I32 no Immediat
ely
- -
174.11 C3Plus.AnalogInput2_Offset_normed Offset X1:IN2
C4_3 no Immediat
ely
- -
174.10 C3Plus.AnalogInput2_UpperLimit upper limit value X1:IN2
I32 no Immediat
ely
- -
175.3 C3Plus.AnalogInput3_FilterCoefficient Filter X1:IN3
I32 no VP - -
175.2 C3Plus.AnalogInput3_Gain Gain X1:IN3
C4_3 no VP - -
