Parker EME
Compax3 - Objects
192-121102 N04 June 2008 423
Bus object No. Object name Object PNU CAN No. Format PD Valid
beginning
I20 I21 / I22
175.9 C3Plus.AnalogInput3_LowerLimit Lower limit value X1:IN3
I32 no Immediat
ely
- -
175.11 C3Plus.AnalogInput3_Offset_normed Offset X1:IN3
C4_3 no Immediat
ely
- -
175.10 C3Plus.AnalogInput3_UpperLimit Upper limit value X1:IN3
I32 no Immediat
ely
- -
176.3 C3Plus.AnalogInput4_FilterCoefficient Filter X1:IN4
I16 no VP - -
176.2 C3Plus.AnalogInput4_Gain Gain X1:IN4
C4_3 no VP - -
176.9 C3Plus.AnalogInput4_LowerLimit Lower limit value X1:IN4
I32 no Immediat
ely
- -
176.11 C3Plus.AnalogInput4_Offset_normed Offset X1:IN4
C4_3 no Immediat
ely
- -
176.10 C3Plus.AnalogInput4_UpperLimit Upper limit value X1:IN4
I32 no Immediat
ely
- -
177.3 C3Plus.AnalogInput5_FilterCoefficient Filter X1:IN5
I16 no VP - -
177.2 C3Plus.AnalogInput5_Gain Gain X1:IN5
C4_3 no VP - -
177.11 C3Plus.AnalogInput5_Offset_normed Offset X1:IN4
C4_3 no Immediat
ely
- -
177.10 C3Plus.AnalogInput5_UpperLimit Upper limit value X1:IN5
I32 no Immediat
ely
- -
206.1 C3Plus.C3FluidNorm_Metric_Imperial Unit system
BOOL no Immediat
ely
- -
2439.3 C3Plus.CurveMemory_Erase Delete valve characteristics
I16 no Immediat
ely
- -
2405.2 C3Plus.DeadBandCompensation_Ch0_A_Side Threshold value on A side output 0
I32 no VP - -
2405.3 C3Plus.DeadBandCompensation_Ch0_B_Side Threshold value on B side output 0
I32 no VP - -
2405.4 C3Plus.DeadBandCompensation_Ch0_Threshold Width of deadband output 0
I32 no VP - -
2405.1 C3Plus.DeadBandCompensation_Ch0_Type Deadband compensation output 0
I16 no VP - -
2415.2 C3Plus.DeadBandCompensation_Ch1_A_Side Threshold value on A side output 1
I32 no VP - -
2415.3 C3Plus.DeadBandCompensation_Ch1_B_Side Threshold value on B side output 1
I32 no VP - -
2415.4 C3Plus.DeadBandCompensation_Ch1_Threshold Width of deadband output 1
I32 no VP - -
2415.1 C3Plus.DeadBandCompensation_Ch1_Type Deadband compensation output 1
I16 no VP - -
2425.2 C3Plus.DeadBandCompensation_Ch2_A_Side Threshold value on A side output 2
I32 no VP - -
2425.3 C3Plus.DeadBandCompensation_Ch2_B_Side Threshold value on B side output 2
I32 no VP - -
2425.4 C3Plus.DeadBandCompensation_Ch2_Threshold Width of deadband output 2
I32 no VP - -
2425.1 C3Plus.DeadBandCompensation_Ch2_Type Deadband compensation output 2
I16 no VP - -
2435.2 C3Plus.DeadBandCompensation_Ch3_A_Side Threshold value on A side output 3
I32 no VP - -
2435.3 C3Plus.DeadBandCompensation_Ch3_B_Side Threshold value on B side output 3
I32 no VP - -
2435.4 C3Plus.DeadBandCompensation_Ch3_Threshold Width of deadband output 3
I32 no VP - -
2435.1 C3Plus.DeadBandCompensation_Ch3_Type Deadband compensation output 3
I16 no VP - -
1100.1 C3Plus.DeviceControl_CommandOnRequest Control command 108 0x2028 I16 yes Immediat
ely
- -
1100.3 C3Plus.DeviceControl_Controlword_1 Control word CW 1 0x6040 V2 yes Immediat
ely
- -
1100.4 C3Plus.DeviceControl_Controlword_2 Control word 2 3 0x201B V2 yes Immediat
ely
- -
1100.8 C3Plus.DeviceControl_DemandValue3 Device demand value C
0x2048 Y2 yes Immediat
ely
- -
1100.5 C3Plus.DeviceControl_OperationMode Operating mode 127/930 0x6060 I16 yes Immediat
ely
X X
1000.5 C3Plus.DeviceState_ActualOperationMode Operating mode display 128 0x6061 I16 yes Immediat
ely
X X
1000.3 C3Plus.DeviceState_Statusword_1 Status word SW 2 0x6041 V2 yes Immediat
ely
- -
1000.4 C3Plus.DeviceState_Statusword_2 Status word 2 4 0x201C V2 yes Immediat
ely
- -
2401.5 C3Plus.DirectionDependentGain_Ch0_Factor_neg
ative
Direction dependent gain
I32 no Immediat
ely
- -
2401.4 C3Plus.DirectionDependentGain_Ch0_Factor_posi
tive
Direction dependent gain
I32 no Immediat
ely
- -
2401.6 C3Plus.DirectionDependentGain_Ch0_InvertType Inversion output 0
I16 no Immediat
ely
- -
2411.5 C3Plus.DirectionDependentGain_Ch1_Factor_neg
ative
Gain factor for negative input values
I32 no Immediat
ely
- -
2411.4 C3Plus.DirectionDependentGain_Ch1_Factor_posi
tive
Gain factor for positive input values
I32 no Immediat
ely
- -
2411.6 C3Plus.DirectionDependentGain_Ch1_InvertType Inversion output 1
I16 no Immediat
ely
- -
2421.5 C3Plus.DirectionDependentGain_Ch2_Factor_neg
ative
Gain factor for negative input values
I32 no Immediat
ely
- -
2421.4 C3Plus.DirectionDependentGain_Ch2_Factor_posi
tive
Gain factor for positive input values
I32 no Immediat
ely
- -
2421.6 C3Plus.DirectionDependentGain_Ch2_InvertType Inversion output 3
I16 no Immediat
ely
- -
2431.5 C3Plus.DirectionDependentGain_Ch3_Factor_neg
ative
Direction dependent gain
I32 no Immediat
ely
- -
2431.4 C3Plus.DirectionDependentGain_Ch3_Factor_posi
tive
Direction dependent gain
I32 no Immediat
ely
- -
2431.6 C3Plus.DirectionDependentGain_Ch3_InvertType Inversion output 3
I16 no Immediat
ely
- -
550.1 C3Plus.ErrorHistory_LastError Current error (n) 115/947.0 0x603F/
0x201D.1
U16 yes - - -
2020.7 C3Plus.ExternalSignal_Accel_Munits Acceleration of the external signal
source
I32 yes - - -
2020.6 C3Plus.ExternalSignal_Speed_Munits Speed value of the external signal
source
C4_3 yes - - -
3921.7 C3Plus.FBI_SignalProcessing0_OutputGreat Interpolation output of the Position
CanSync, PowerLink
Y4 no - - X
3921.8 C3Plus.FBI_SignalProcessing0_Source Switching the position source of the
interpolator
I16 no Immediat
ely
- X
1141.10 C3Plus.GEAR_FFW_mode Control bits for feedforward with
source CANSync/EthernetPowerLink
0x2097 U16 no Immediat
ely
- X
1141.4 C3Plus.GEAR_mode Source selection Gearing
0x2055 U16 no Immediat
ely
- -
