Parker Compax3 Fluid T40

Parker EME
Specifications
192-121102 N04 June 2008 455
Inputs and outputs
Controller type Compax3 F001 D2
8 control inputs
24VDC / 10kOhm
4 control outputs
active HIGH/short-circuit protected, 24 V / 100
mA
4 analog current inputs
14Bit
2 analog voltage inputs
14Bit
4 analog outputs
16bits, current or voltage
2 analog monitor ouptuts
8bits
COM ports
RS232
 115200 baud
 Word length: 8 bits, 1 start bit, 1 stop bit
 Hardware handshake XON, XOFF
RS485 (2 or 4-wire)
 9600, 19200, 38400, 57600 or 115200
baud
 Word length 7/8 bit, 1 start bit, 1 stop bit
 Parity (can be switched off) even/odd
 2 or 4-wire
Supported valves and feedback systems
Valves
 D1*FH series
Absolute encoder
 Analog 0..20mA, 4..20mA, ±10V
 Start/Stop - interface
 SSI interface
 EnDat 2.1-interface
 1VSS (max. 400kHz) Interface, 13.5bits /
graduationof the scale
 RS422 encoder (max. 5MHz), internal
quadrature of the resolution
EMC limit values
EMC interference emission
Limit values according to EN 61000-6-4: 2001
for the industrial environment
EMC disturbance immunity
Limit values according to EN 61000-6-2: 2001
for the industrial environment
