Parker Compax3 Fluid T40

Parker EME
Specifications
192-121102 N04 June 2008 457
IEC6113-3 functions
General
 Programming based on IEC61131-3
 Up to 6000 instructions
 650 16 bit variables
 200 32 bit variables
 Recipe table with 288 variables
 3x16-bit retain-variable
 3x32-bit retain-variable
PLCOpen function modules
 Positioning: absolute, relative, additive,
endless
 Electronic Gearbox (Gearing)
 Machine Zero
 Stop, activating the drice, quit
 Position, device status, reading axis error
IEC61131-3 standard modules
 Up to 8 timers (TON, TOF, TP)
 Triggers (R_TRIG, F_TRIG)
 Flip-flops (RS, SR)
 Counters (CTU, CTD, CTUD)
Device-specific function modules
 generates an input process image
 generates an output process image
 access to recipe table
Inputs/Outputs
 8 digital inputs (24V level)
 4 digital outputs (24-V level)
 Optional addition of 12 inputs/outputs
