2-48 Hardware Description
Specifications
This section gives physical, environmental, electrical, and safety specifications for the
Information Center system components. Also provided are requirements for displays
connected to Information Center systems and an external modem for the Database Server.
Caution The following specifications are for units shipped at the time of this manual’s
publication. Units shipped with later systems may vary, with newer models substituted
as they become available.
Physical The following table gives the current specifications of the maximum dimensions and weights
of each component in the Information Center System.
Table 2-4. Physical Specifications of Information Center System Components
Philips Component
Product
Part #
Height
cm (in.)
Width
cm (in.)
Depth
cm (in.)
Weight
kg. (lbs.)
Server (M3154) M3168A 46.88 (18.46) 22.07 (8.69) 71.12 (28.00) 23.04 (50.8)
PC M3167B 16.7 (6.6) 44.8 (17.65) 16.8 (6.6) 9.1 (20)
Medium CRT Display WW (not Europe) M3161 41.5 (16.3) 44.2 (17.4) 43.5 (17.1) 19 (42)
Medium CRT Display - Europe M3161 41.5 (16.3) 44.2 (17.4) 43.5 (17.1) 19 (42)
Large CRT Display M3162 49.1 (19.3) 49.8 (19.6) 48.6 (19.1) 32 (71)
Large Flat Panel Display 862103 45.5 (17.9) 45.0 (17.7) 24.5 (9.6) 13.6 (29.9)
Medium Touch Flat Panel Display 862428 42.9 (16.9) 43.4 (17.1) 24.4 (9.62) (25)
2-way Video Splitter 862096 4.4 (1.75) 11.8 (4.63) 12.1 (4.75) 0.45 (1)
6-Way Video Splitter 862097 10.8 (4.27) 21.3 (8.4) 15.9 (6.25) 3.6 (8)
Keyboard C4735A 4.6 (1.8) 46.0 (18.1) 18.9 (7.5) 1.1 (2.4)
C3758A 5.1 (2.0) 46.4 (18.3) 17.8 (7.0) 1.1 (2.4)
Keyboard-Video-Mouse Switch 862098 4.8 (1.9) 20.6 (8.1) 12.7 (5.0) .77 (1.7)
Philips 2-Channel Recorder/Rack M1276A #201/
M1116B
14.9 (5.9) 26.0 (10.2) 15.0 (5.9) 1.6 (3.5)
2-Channel Recorder/Rack Power Supply M3180-60040 40.3 (15.9) 7.75 (3.05) 12.9 (5.08) 0.34 (0.75)
4-Channel Recorder Power Supply M3160A 24.9(9.8) 14.0(5.5) 19.0(7.5) 2.5 (5.5)
LaserJet Printer 2300L 26.0 (10.2) 41.3 (16.2) 45 (17.7) 14.3 (31.6)
Printer Hub AT-FS708 3.6 (1.44) 24.92 (9.82) 11.63 (4.58) .89 (1.95)
UPS (650 VA, 120 V)) 0950-2832
16.8 (6.6) 11.9 (4.7) 36.1 (14.2) 11.4 (25.0)
UPS (650 VA, 230 V) 0950-3406
Power Distribution Module M3166-60000 16.0 (6.3) 25.9 (10.2) 51.0 (20.1) 20 (44)
UPS for Database Server
(1000 VA, 120V)
M3882-60001
21.6 (8.5) 17.0 (6.7) 43.9 (17.3)
19.1 (42)
UPS for Database Server (Japan)
(1000 VA, 100V)
M3884-60001 19.1 (42)
UPS for Database Server
(1000 VA, 230V)
M3883-60001 18.9 (41.5)
