Mounting
Hardware Description
2-29
Mounting
A variety of hardware is available for mounting Information Center components for
convenience of use and efficiency of the work area.
Display
Mounts
Display mounts are available to permit easy viewing of video screens in a variety of locations
and directions. For medium displays, a surface swivel mount is available for rotating the
display screen over a 270
o
angular range. See Figure 2-29.
Wall and ceiling mounts may also be available for mounting remote slave displays at
locations where they can be conveniently seen by the clinician.
Figure 2-29 Display Swivel Mount
Keyboard
Mounts
Two options are available for the computer keyboard -- a table top garage (M3180A #A09)
and an under table drawer (M3180A #A08). These permit putting the keyboard out of the
way when not being used, thereby providing additional work surface area. Installation
procedures for these units are described in installation notes that come with the units. See
Figure 2-30
Figure 2-30 Computer Keyboard Mount Options
270
o
18.5
18.5
Table Top
Under Table
Garage
Drawer
