Philips IntelliVue Series - Panel Descriptions

System Components
2-6 Hardware Description
Panel
Descriptions
Figure 2-4 D510 PC Workstation Rear Panel
Power Cord Connector
Voltage Select Switch
Mouse Connector
Keyboard Connector
First Serial Connector (COM A)
Display Connector (not used if Dual Display)
Parallel Connector
Sound Card
Dual Video Card
SDN Card
Second Serial
Connector (COM B)
(Optional)
LAN Connector
10BT
100TX
-
Hospital LAN
NIC Card (Optional)
