Configuration
Software Installation & Configuration
6-47
Note Central Station: and SCC: fields are not active (n/a) for M3151 Clients and for Information
and Centers with M3/M4 Only monitors.
SCC and clinical Unit assignments are made in Network Configuration.
Warning If the # of Patients is decreased when beds are assigned to Patient Sectors, a ? appears in
the Sector column of Beds assigned to invalid Sectors in Monitor/Overview Beds. A
warning message states that these beds will not be monitored or overviewed if they are
not reassigned to a valid Patient Sector.
Note For setups with 8 rows of Patient Sectors and more than 1 Wave per Sector, Show Alarm
Limits will automatically be unchecked because there is not sufficient display space for Heart
Rate Alarm Limits. Show Alarm Limits is not active for M3/M4 patient monitors because
these monitors do not display alarm limits. Show alarm limit will be automatically unchecked,
if 8 rows and 1 column (not 2 columns) is selected.
Monitor/Overview Beds displays the assignment of beds to Patient Sectors.
Columns in this field are:
Associations • Central Station - Read Only. # of this Information Center -- 1 - 6. The # of each Information
Center on each SCC must be different. Clicking the arrow to the right of the field displays a list
of the Central Station #s that are available for the SCC the Information Center is connected to.
Central Station #s already in use will be grayed out and are not selectable. Clicking on any
Central Station # changes the # being used for that Information Center.
• SCC - Read Only. Identifies the SCC supplying patient monitoring data to this device
• Monitoring - Read Only. Set whether the assignment of patient monitors will be Fixed or Flex
– Fixed means that assignment of a patient monitor (bedside or telemetry) to a Bed Label is fixed
and cannot be changed by the user. This is the Factory Default setting.
– Flex means that patient monitors (bedside and telemetry) can be assigned to different Bed
Labels by the user. These reassignments are made in Sector Setup.
• Unit - Read Only. Identifies the name of the clinical Unit where the patient monitors for the
device selected in Central Station are located
Field Description
Field Description
Bed Label Label assigned to the patient bed where the monitoring equipment is located. An icon to the left
of the number indicates whether the monitor is a hardwired, telemetry or wireless unit
Unit Name of the clinical Unit where the patient monitor is located.
Branch #/Port # Logical Branch Number (LBN) of the SDN branch on the SCC that the patient monitor is
connected to or the port number of a switch that M3/M4/IntelliVue Patient Monitors are
mapped to
Equip. Label/Monitor
Label
Label assigned to the monitoring equipment.
