Network Names and IP Addresses
Hardware Installation
5-33
Network Names and IP Addresses
When all devices have been installed, interconnected, and turned on, the next step is to
identify their names and locations on the Network. A variety of names and location
identifiers are used for this purpose. The names and addresses for each Network device --
Switches, Information Centers, Clients, and Printers -- must be unique so they can be
properly located by the Database Server and other Network devices.
IP Address Internet Protocol (IP) Address is a 32 bit binary number that uniquely identifies the device
on the Network. The IP Address is generally in dotted decimal format, which consists of 4
sets of numbers separated by dots, e.g. 172.31.252.1. Part of the IP Address identifies the
network and part identifies the device.
For the M3185 Clinical Network, a range of possible IP addresses has been set for each type
of Network device. If separate systems are being installed today with an expectation of
connecting them in the future, do not use the same names or IP addresses. This will save
time later when they are connected together. The IP Address ranges are given in Table 5-1.
Warning IP Addresses outside the ranges given in Table 5-1 have not been tested by Philips and
are not supported by Philips software.
Table 5-1. Range of IP Addresses for Network Devices
Device
Range of
IP Addresses
Recommended
IP Addresses
M2/M3/M4/IntelliVue Patient Monitors 172.31.16.0 -
172.31.79.255
These IP Addresses are automatically allocated by
Philips Software
RangeLAN2 Wireless Access Points 172.31.234.0 -
172.31.240.255
172.31.234.0 -172.31.234.15
M3150 Information Centers 172.31.101.0 -
172.31.150.255
172.31.101.0 -
172.31.101.7
M3151 Information Center Clients 172.31.151.0 -
172.31.200.255
172.31.151.0 -
172.31.151.7
M3154/M3169 Database Server
LAN Card 172.31.221.0 -
172.31.227.255
172.31.221.0
Information Center Web Card 172.30.221.0 -
172.30.227.255
172.30.221.0
M3185 Core/Edge Switches 172.31.252.0 -
172.31.253.255
172.31.252.0 - 172.31.252.9
M3159 Networked LaserJet Printers 172.31.254.1 -
172.31.254.4
172.31.254.1 -
172.31.254.4
M3165 Paging Transmitters/Serial Servers 172.31.248.0 -
172.31.248.255
172.31.248.0 -
172.31.248.7
