Troubleshooting
Maintenance, Troubleshooting, and Repair
7-57
Telemetry
Services
The Telemetry Services tool is used by Information Centers to access information from
Telemetry Mainframes. Clicking on Telemetry Services in the Support Logs menu of the
Service window brings up the Telemetry Mainframe Services window shown in Figure
7-24. It is available in monitoring mode only.
Figure 7-24 Telemetry Services Window
Notes Telemetry Mainframe Services windows are read only and cannot be edited.
To change telemetry settings, use the Telemetry Service Tool.
To change frequency settings for telemetry receivers, use the Telem Freq. application in the
Unit Settings menu.
For more detailed information on telemetry mainframes and transmitters, refer to their Service
Manuals.
The Telemetry Mainframe Services window has 6 tabs in the upper left corner that access
the windows listed below. Each window contains the following controls on the left side of the
window:
Telemetry Mainframes: field for selecting the telemetry mainframe number whose
information is to be displayed.
Record RF History button for producing a recording strip of all receiver RF histories
for the currently selected telemetry mainframe.
Refresh button for updating the information in the window being viewed to current
values
Note If Telemetry Mainframe configurations are changed, both the Telemetry Mainframe and the
Information Center must be rebooted to see the changes in the Telemetry Mainframe
Services window. The Refresh button will not update this window if configurations change.
