UPS Mount Wall mount hardware for the UPS, 60V Recorder Power Supply, and 2-way Video Splitter is
shown in Figure 2-33.
Figure 2-33 UPS, 60V Power Supply, 2-Way Video Splitter Mounting Hardware
60V Power Supply
2-way Video Splitter
Bracket
UPS
Wall Mount Bracket
Bracket
Bracket
Wall Channel
Mounting Cover
Wall Mount Assembly Detail
Wall Mount Assembly with Cover
Wall Mount Assembly
